High Efficiency Double Station Automatic Bottle Blow Molding Machine for Plastic Bottle Production

weight (t) : 5.5

Model NO. : DSB70II-2

Station : Double Station

Suitable Material : HDPE,PP,PVC,PS,PETG,LDPE

Made in : China

Trademark : DAWSON

Language settings : Chinese and English operation panel

video outgoing-inspection : Provided

plastic processed : PP, HDPE, PVC, PE/PP

Place of Origin : Jiangsu, China

dimension(l*w*h) : 3.9*2.0*2.6

Clamping Force (kN) : 65

output (kg/h) : 75

automation : Automatic

screw heating power(kw) : 6

mold platen size(height)(mm) : 320

air pressure(mpa) : 0.6

power (kw) : 101.2

machinery test report : Provided

core components : PLC, Engine, Bearing, Gearbox, Motor, Gear

Brand Name : DAWSON

voltage : 220V,380V

Screw L/D Ratio : 24

screw diameter (mm) : 65

No. of Screw Heating Zone : 3

extruder motor power(kw) : 18.5

mold platen size(width)(mm) : 290

air comsumption(m³/min) : 0.6

die head heating power(kw) : 5.7

key selling points : Easy To Operate

warranty : 1 Year

Cycle : 440-480

Clamping System : Toggle Type Clamping System

Clamping force : 110kw

Screw heating power : 9kw

MOQ : 1

Price : $22,800-28,800
